· Do not immerse the main unit or control panel in water or rinse them directly with water.
· Use the automatic cleaning and disinfection function. The combination of water pressure and cleaning solution can remove residual liquid stains from the glass tank, ensuring cleaness to extend the machine lifespan.

Automatic cleaning (recommended after each use)
1. Ensure all beverages are drained, and the glass tank is empty;
2. Remove the extraction basket and replace it with the cleaning parts. After use, manually clean the extraction basket to prevent residue from remaining in the mesh;
3. Add an appropriate amount of cleaning solution and close the glass tank cover;
4. Click the automatic cleaning (the machine will automatically fill with water twice; no need to add cleaning solution for the second time) (approximately 10 minutes);
5. Cleaning complete.
Automatic Disinfection Function(once a week)
1. Ensure all beverages are drained, and the glass tank is empty;
2. Assemble in "Extraction Mode", ensuring the Extraction Basket is clean and tidy;
3. Add an appropriate amount of disinfectant cleaner, then close the Extraction Basket Coverand fasten the Butterfly Nut ;
4. Start the automatic disinfection for function(the device will automatically fill with water twice; no need to add disinfectant the second time)(approximately 10 minutes);
5. Disinfection complete.

Note:

1. Keep the machine away from flammable and explosive materials;
2. Before use, check if the rated voltage on the product matches local voltage.
3. Do not plug in the machine if parts are missing or damaged.
4. Ensure stable water pressure at the inlet to avoid stopping the extraction process;（It is recommended to install a 2-kg pressure reducing valve into the water inlet pipeline to ensure the stability of water flow.）
5. Before operation, place the cold brew liquid outlet hose into a container to avoid spillage ;
6. Use only under the supervision of a fully competent adult;
7. Place the machine on a flat surface and out of reach of children;
8. Use the product in a well-ventilated area. Do not block the air inlet or outlet;
9. Do not move or tilt the machine while it is operating;
10. Do not leave the machine running unattended for long time;
11. Ensure the main unit is dry and all parts are correctly installed before use;
12. Keep the glass tank and extraction basket clean. Clean them promptly after each use to prevent stubborn stains and odors;
13. Do not tilt the machine to pour out residual water; use the drainage program instead;
14. Avoid letting water enter the internal components during cleaning to prevent damage;
15. If the machine is not used for a long time, ensure the glass tank and extraction basket are clean and dry to avoid stubborn stains;
16. Do not plug or unplug the power cord or operate the machine with wet hands to avoid short circuits or electric shock;
17. Do not disassemble or modify the machine components.

Ensure proper use of this product to avoid personal injury

1. Keep the machine away from flammable and explosive materials.
2. Before use, check if the rated voltage on the product matches local voltage.
3. Do not plug in the machine if parts are missing or damaged.
4. Ensure stable water pressure at the inlet to prevent extraction from stopping.
5. Place the outlet hose into a container before starting the machine to avoid spillage.
6. Place the machine on a level surface to avoid tilting, which can affect performance.
7. Keep the glass tank and extraction basket clean; and besure to clean it after each use.
8. Do not tilt the machine to pour out residual water; please use the drainage program.
9. Avoid immersing water inside the machine during cleaning to prevent damage to components.
10. If the machine is not used for a long time, ensure the glass tank and extraction basket are clean and dry.
11. Do not plug/unplug the power cord or operate the display with wet hands to avoid short circuits or electric shock.
12. Do not disassemble or modify the machine components.
13. Clean all pipes after daily use to prevent residue from causing unpleasant odor or food safety issues.
14. Keep the machine out of reach of children to prevent personal injury and machine damage.
15. The product is compatible with VAC85-264; ensure proper power connection to avoid damage.
16. If the power cord is damaged, do not plug it in; contact authorized service or a qualified technician for replacement to avoid personal ingury.
17. Only use water at or below room temperature; hot water can damage the pipes and affect the service life of the machine.
18. If the machine is damaged, do not disassemble or modify it without permission; contact authorized technicians for repair and maintenance.

According to the national“Three Guarantees Law”, including repair, replace, return service.The product is entitled to 1 year warranty period. The warranty period is calculated from the date of purchase as indicated on the invoice. If the warranty has expired or the issue is not covered under free repair terms, you may contact our company for paid repair services. After-sales service hotline: 860510-83331234

Damage(s) to the equipment caused by one or more of the following reasons shall not be covered under the warranty.
1. Operation of the equipment contrary to the user manual instructions；
2. Consumer-caused damage due to improper handling, use, maintenance, or storage；
3. Use of the equipment in an unsafe state or manner；
4. Damages caused by installation/repairs performed at non-authorized service centers (including self-installation or unauthorized modifications)；
5. Equipment malfunction due to unauthorized replacement of control systems；
6. Damage arising from non-compliant usage environments (e.g., power supply, voltage, ventilation) as specified in the product manual；
7. Lack of valid purchase invoice or proof of warranty period coverage.
8. External force majeure events (e.g., earthquakes, tsunamis, floods, or other natural disasters)；
9. Voidance of warranty upon product transfer of ownership.

Contact the manufacturer or authorized technical support if the problem is not solved or in case of other types of faults. Do not disassemble the machine unless you are a qualified professional.

· Product specifications and designs aresubject to change without notice.
· In case of discrepancies between the Chinese and English versions, the Chinese version shall prevail.

Verify that all components are included before machine installation.

1/4 inch transparent drinking water tube (2m) (Quantity × 4)
3/8 inch transparent drinking water tube (2m) (Quantity × 4)
1/2 inch semi-transparent drinking water tube (2m) (Quantity × 11)
1/2 inch L-type plug-in connector (Quantity × 4)
1/2 inch elbow connector (Quantity × 2)
3/8 inch L-type plug-in connector (Quantity × 2)
1/4 inch L-type plug-in connector (Quantity × 2)
1/4 inch to 3/8 inch connector (Quantity × 1)
3/8 inch to 1/2 inch connector (Quantity × 1)
pipe-cutting tool (Quantity × 1)
Basket cover sealing ring (OD: 160mm, wire diameter: 3.1mm) (Quantity × 1)
Basket cover bolt sealing ring (M8×20×2 mm) (Quantity × 1)
Extraction water injection nozzle sealing ring (OD: 15×2 mm) (Quantity × 1)
3/8 inch pressure reducing valve (Quantity × 1)
Power cord (Quantity × 1)
Mesh Screen (Quantity × 1)
User manual (Quantity × 1)
Packaging box (Quantity × 1)
